Description
Ideal for smoke and fume extraction in the welding and manufacturing industries, this mobile fume extractor is equipped with the following features:
- High efficiency washable filter and activated carbon in both doors. There is also an optional throwaway paper filter or a 99.997% HEPA filter.
- Portability and flexibility to accommodate use in hard-to-reach places
- The Snorkvac™ Fume Extractor Snorkel Arm which is 10ft. (3M) long and 6″(160MM) wide. The Snorkvac™ Fume Arm is uniquely designed and externally supported to minimize the restriction to the air flow and minimizing any pressure drop. This makes adjustments and hose replacements much easier than an internally supported arm.
- Air diverter increases capture distance and gives uniform air flow
- Standalone adjustable contactor overload to maximize the protection to the motor. The top panel (Electrical Control Panel) of the machine allows easy access to the electrical components.
- Ease of movement with 2 – 5” fixed casters and 2 – 5” rotating casters with a brake.
- Units are of sturdy construction and flame resistant as they are manufactured out of 14 gauge cold rolled steel and painted with a baked-on powder coat.
- Simple operation provides a safer work environment for all team members.
To conclude:
A powerful solution for welding, grinding, sanding, painting, oil mist, and more. Captures contaminants at the source to protect the operator and recirculates clean air—no added heating or cooling costs.
A Very Profitable Investment
Enviroflex welding fume extractors decrease the need for general ventilation as well as the amount of dust in the air. Less dust will give less wear on the machinery, less cleaning in the workshop and in the office, better lighting (no dirty lamps), cleaner material handling, higher working tempo and less absence bronchial illnesses. Few other investments will cut costs in the same way.
Downloads:
📘 MAC CATALOG
